100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume

Zhengzhou Zhenheng Construction Equipment Co., Ltd.
Contact Now
    Buy cheap 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume from wholesalers

    Buy cheap 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume from wholesalers
    • Buy cheap 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume from wholesalers
    • Buy cheap 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume from wholesalers
    • Buy cheap 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume from wholesalers
    • Buy cheap 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume from wholesalers

    100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume

    Ask Lasest Price
    Brand Name : ZHENHENG
    Model Number : YHZS100 Mobile concrete batching plant
    Certification : SGS, ISO, BV, CE
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 30 sets per month
    Delivery Time : 7-15 working days after confirm order
    • Product Details
    • Company Profile

    100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume

    100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume


    Description of 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume

    YHZS 100 type mobile concrete batching plant, is one kind of highly integration concrete mixing plant. It is designed for customer which need to change working site frequently. All components is fixed on the chassis of concrete mixing plant, and it is with wheel which is easily for movement. This plant is completely equipped with concrete batching system, mixing system, weighing system and fully automatic control system. It occupy less plan and it is suitable for medium and small project like water and electricity, road construction, port, bridge etc, such movable engineering construction project.


    Introduction of 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume
    1. Portable mobile rmc ready mix concrete batching plant with 100m3/h capacity.
    2. Adopt advanced technology and are designed and manufactured as per International standards.
    3. It can produce any type of concrete to meet customer requests with different type mixers, like twin shaft mixer and planetary mixer.
    4. Were widely used in construction projects, ready mix concrete production and concrete prefabrication factory.
    Advantages


    Technical Parameters of 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume

    Model

    YHZS100

    Theory capacity

    100m³/h

    Discharging height

    3800mm

    Total power

    100kw

    Approximate weight without silo

    About 26T

    Dimension(L * W * H)

    18.5m X 3.9mX 8.2m

    Moving size(L * W * H)

    18.1m X 2.3m X 4.3m

    Mixing System

    Model of Mixer

    JS2000

    Mixing motor

    37kw×2

    Charging volume

    3200L

    Discharging volume

    2000L

    Aggregate System

    Aggregate bin

    10m³×2-4

    Cylinder

    SCU φ100

    Aggregate conveyer System

    Motorized Pulley

    WII-500x1000

    Conveyor belt

    W1000×L28000mm

    Measurement System

    Cement weighing hopper

    1120KG

    Water weighing and support frame

    450KG

    Additive weighing and support frame

    50KG

    Pneumatic ControlSystem

    Air compressor

    0.9m³/min 1 sets

    Electromagnetic gas valve

    4V410 8 sets

    Moving System

    Towing pin

    φ50mm/ φ90mm 1 set

    Tyre

    75R16 4sets

    Computer Control System

    Industrial control computer

    1 set

    Display

    17” liquid crystal LCD


    Q: Can you test our order before shipping?
    A: Yes. All of our goods will test in factory before shipping to customer.


    Q: How long it takes to do all the installation
    A: It's at most 5days processing and manufacturing for single machine,for production line,at most 15days.


    Q: Can we visit your factory?
    A: Yes. You can visit our factory at anytime you want.

    Q: Can you put our logo on the machine?
    A: Yes,it is available.LOGO and color are usually as per customer's requirement.

    Q: What’s the warranty time?
    A: From the date of shipment, 1 year or 1500working hours, whichever comes first.

    Q: What’s your payment term?
    A: We accept T/T(30% down payment and balance before shipping) and L/C mostly, but if you prefer other payment terms please contact us for further information.

    Q: How long is your delivery time?
    A: Usually, it is 7-10 workdays if the goods are in stock, or it is 15-20 working days if the goods are not in stock, it is according to quantity.

    Q: Can we paint our label on your product?

    A: Of course. OEM and ODM are acceptable, please send us your logo or brand, we’ll paint for you.


    More Reference Photos of 100m3 / H Twin Shaft Mixer YHZS100Mobile Concrete Batching Plant 2 X 10m3 Aggregate Bin Volume
