    Small Mobile Concrete Batch Truck , 1.6m3 Self Loading Concrete Volumetric Mixer

    Ask Lasest Price
    Brand Name : ZHENHENG
    Model Number : 1.6
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 30 SET PER MONTH
    Delivery Time : 7-15 working days after confirm order
    • Product Details
    • Company Profile

    Small Mobile Concrete Batch Truck , 1.6m3 Self Loading Concrete Volumetric Mixer

    ZH420 Portable cement transit truck self loading mobile concrete mixer for sale


    Description of Mobile Self Loading Concrete Mixer Truck High Efficiency For Urban Construction


    Combine concrete truck mixer with concrete mixer, self loading concrete mixer can automatic feeding, metering, and mixing to discharge, and more, it can realize the transportation and site construction operations, which greatly improves the work efficiency, reduce production cost and time.

    Widely used for Construction of rural roads, filling trenches along the roads, construction of airports, landmark buildings, construction sites,Pavement of factory buildings, use of mountain roads, mountain construction projects, water conservancy projects, micro-mixing plants,Subway, defense, etc.
    Note: All projects that can use concrete can be used, and can be used on mountain roads.

    Parameters of Mobile Self Loading Concrete Mixer Truck High Efficiency For Urban Construction


    NameItemSpecification
    Whole truckNet weight9000 KG
    Gross weight12675 KG
    TransmissionFull Hydraulic
    4 WD
    BrakeAir Brake
    ChassisOff-road
    Loader bucketcapacity0.6m3
    ControlHydraulic
    Tilt angle30%
    SpeedHigh0-25KM/H
    Low0-9KM/H
    Mini turning radius6.5M/R
    Tyre model16/70-20 wire typres
    EngineRated Power/RPM95KW/2400RPM
    Max.Torque/RPM460N.M/1400RPM
    Cylinder4
    StarterElectric
    Cooling typewater cooling
    Maxing DrumOutput capacity4.2 M3
    Bank Angle16 °
    Rotation Angle19-21R/min
    ChuteSwing Angle≥60°
    Angle controlHydraulic
    SizeLong:176cm
    Short: 40cm
    LoaderWeighing modelcomputer control
    Concrete StandardC15.C20.C25 C30
    AccuracyCement≤±2%/time
    Relative Error≤±3%/time
    water≤±1%/time
    Additive≤±1%/time
    Admixture≤±2%/time
    Loader controlHydraulic 4 way stick
    Over size6252x2200x2892 mm

    Small Mobile Concrete Batch Truck , 1.6m3 Self Loading Concrete Volumetric Mixer


    Advantages of Mobile Self Loading Concrete Mixer Truck High Efficiency For Urban Construction


    1. ITALY LEADING DESIGN,AUTOMATIC FEEDING MIXING SYSTEM

    2. SIMPLE AND CONVENIENT OPERATION

    3. HIGH EFFICIENCY OUTPUT,SAVE TIME AND LABOR,SAVE COST

    4. THE PERFECT COMBINATION OF MIXING TRUCK AND LOADING CAR



    Working process of Mobile Self Loading Concrete Mixer Truck High Efficiency For Urban Construction


    1. By charging scoop,small amount of sand and gravel is loaded into the mixing drum.


    2. Self-loading concrete mixer interior injected into water, when the supply water flow is completed, adding cement, self-loading concrete mixer will run to the designated place to unload concrete, at the same time, the mixing drum will keep rotating to ensure that the concrete dose not condense.


    3. Mixing drum is equipped with the screw type of blade,, the maximum savings in working time and raw material.


    4. After working, the completion of the need for equipment to be cleaned to ensure that the normal work in the future.


    FAQ


    Q1. What is the machine advantage? Why I choose from you?
    A: Adopting famous brand engine and parts, ensure long life service, all the structure parts are produced and checked by our engineers. Each machine is carefully tested before send to customer.


    Q2: How many units can be put in container?
    2 units can be in a 40HQ container. None packing,and will fixed with wire ropes.


    Q3: What payment term can I use?

    100% TT--30% TT in advance; the balance before shipment

    100% irrevocable LC at sight.
