    40m3/H Diesel Concrete Pump

    Ask Lasest Price
    Brand Name : ZHENHENG
    Model Number : HBTS40 -40m³/h Diesel Concrete Pump
    Certification : SGS, ISO, BV, CE
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 sets per month
    Delivery Time : 7-15 working days after confirm order
    • Product Details
    • Company Profile

    40m3/H Diesel Concrete Pump

    Building Equipment 40m3/H Output Diesel Concrete Pump Trailer-Mounted


    Brief Introduction to 40m3/H Diesel Concrete Pump


    On the basis of mature electric commutation technology,we have developed overall hydraulic concrete pumps with excellent performance. It greatly improves the reliability of the machine and makes sure it can work in any hard condition. Our various motor concrete pumps( diesel engine concrete pumps) mainly cover capacity from 30-120m³/h and pressure from 5-20Mpa.

    In order to meet the demand of open country and other no power supply constructions, we research and developed the diesel engine concrete pump. Our concrete pump is set of mechanical, electrical and hydraulic technology as one, with reliable performance of smooth operation and strong pumping capability. The diesel engine is with advanced high quality, low emission, low fuel consumption, meet the advanced standard. Reliability and stability is guaranteed by automatic engine regulation.


    Parameters to 40m3/H Diesel Concrete Pump


    Item

    HBTS40-10-78R

    Max Theoretical Concrete Output

    40 m3/h

    Max Theoretical Conveying Distance

    (vertical Height/Horizontal Distance)

    150/500 m

    Max Concrete outlet Pressure

    10 Mpa

    Distribution Valve

    S Valve

    Max Aggregate size

    30 mm

    Concrete Slump

    100~200 mm

    Concrete Cylinder Diameter

    Φ160×1000 mm

    Oil Tank Diameter

    Φ100×φ63×1000 mm

    Hopper Capacity/Filling Height

    0.4/1100 m3/mm

    Concrete Pumping Pressure

    23 Mpa

    Hopper Mixing Pressure

    14 Mpa

    Oil Tank Capacity

    200 L

    Cleaning Mode

    High Pressure Washing

    Diesel Motor

    78 kw

    Oil Pump

    140ml/r (Korea KAWASAKI)

    Valve Group

    Germany Bolseen

    Hydraulic Hose

    Italy MANULI

    Electric

    CHNT/Schneider

    Dimension(L×W×H)

    5150×1600×2150 mm

    Weight

    4300 kg

    40m3/H Diesel Concrete Pump

    Features to 40m3/H Diesel Concrete Pump


    1. Reliable performance: adopt Italy hydraulic drive, which reduce reversing impact. S Valves system is easy for maintaining.

    2. Complete machine can be taken apart into two, easy to transport and install in mining construction location.

    3. Core parts are Japanese Kawasaki original, equipment lifetime and quality is reliable.



    1. Hydraulic system


    Double open hydraulic loops with 2 pumps.The reliability of the whole system is also much higher as well as the components' life is prolonged greatly. This is convenient for judgeing and removing trouble.

    2. Electric control system


    Compared with domestic product, the electric control system is simplest, the element quantity is fewest and its reliability is the highest.

    Adopting proximity switch in hydraulic cylinder can realize changing direction with non-touch, which ensures that the direction can be changed reliably.

    3. Diesel Engine


    The pump adopt Weichai diesel engine, a first-class brand in China. It can ensure the power supply of the concrete mixer pump.

    4. Cooling system


    The radiator equipment makes the working oil temperature of hydraulic system below 70℃ and makes the machine in normal status.


    Q1. Why Choose Us?
    A:1.Over 30 years' production and design experience. We have rich experience in manufacturing construction machines.


    Q2. Warranty?
    A:12 Month after installation.


    Q3. Can you put our logo on the machine?
    A: Of course. OEM and ODM are acceptable, please send us your logo or brand, we’ll paint for you.


    Q4. Can we visit your factory?
    A: Yes. You can visit our factory at anytime you want.
