    JS1500 Forced Type Mixer 2400L Portable Concrete Mixing Plant

    Ask Lasest Price
    Brand Name : ZHENHENG
    Model Number : YHZS75 Mobile concrete batching plant
    Certification : SGS, ISO, BV, CE
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 30 sets per month
    Delivery Time : 7-15 working days after confirm order
    • Product Details
    • Company Profile

    JS1500 Forced Type Mixer 2400L Portable Concrete Mixing Plant

    JS1500 Forced Type Mixer YHZS75 Mobile Portable Concrete/Cement Batching Plant

    Main features of JS1500 Forced Type Mixer YHZS75 Mobile Portable Concrete/Cement Batching Plant

    JS1500 concrete mixer
    JS1500 concrete mixer mixing system consists of motor, pulley, gearbox, stirring device, mixing drum and other components.
    Batching Machine
    8m³×2-4 volume concrete batching machine can effectively ensure the accuracy of cement, sand, gravel, etc. And further improve the accuracy of weighing by using the electronic weighing system.

    Belt conveyor
    The purpose of conveying material is realized by conveying dry particles from top to bottom through air trough. Energy saving, no noise, maintenance-free and accurate measurement.

    Control system
    The product adopts dual-machine automatic control computer or manual control system, and the automatic fault diagnosis program is simple and safe to operate.

    Bolted cement silo
    Cement bins is a closed tank for storing bulk material, suitable for storing grain, cement, flyash and other bulk materials. The tank is equipped with a material level system, which can show the location and amount of materials.

    Main Parameters of JS1500 Forced Type Mixer YHZS75 Mobile Portable Concrete/Cement Batching Plant

    Model

    YHZ75

    Theory capacity

    75m³/h

    Discharging height

    3800mm

    Total power

    86kw

    Approximate weight without silo

    About 22T

    Dimension(L * W * H)

    18.5m X 3.9m X 8.2m

    Moving size(L * W * H)

    18.1m X 2.3m X 4.3m

    Mixing System

    Model of Mixer

    JS1500

    Mixing motor

    30kw×2

    Charging volume

    2400L

    Discharging volume

    1500L

    Aggregate System

    Aggregate bin

    8m³×2-4

    Cylinder

    SCU φ100

    Aggregate conveyer System

    Motorized Pulley

    WII-500x800

    Conveyor belt

    W800×L28000mm

    Measurement System

    Cement weighing hopper

    900KG

    Water weighing and support frame

    330KG

    Additive weighing and support frame

    40KG

    Pneumatic ControlSystem

    Air compressor

    0.9m³/min 1 sets

    Electromagnetic gas valve

    4V410 8 sets

    Moving System

    Towing pin

    φ50mm/ φ90mm 1 set

    Tyre

    75R16 4sets

    Computer Control System

    Industrial control computer

    1 set

    Display

    17” liquid crystal LCD

    More Photos of JS1500 Forced Type Mixer YHZS75 Mobile Portable Concrete/Cement Batching Plant




    Q: Can you test our order before shipping?
    A: Yes. All of our goods will test in factory before shipping to customer.
    Q: How long it takes to do all the installation
    A: It's at most 5days processing and manufacturing for single machine,for production line,at most 15days.
    Q: Can we visit your factory?
    A: Yes. You can visit our factory at anytime you want.

    Q: Can you put our logo on the machine?
    A: Yes,it is available.LOGO and color are usually as per customer's requirement.

    Q: What’s the warranty time?
    A: From the date of shipment, 1 year or 1500working hours, whichever comes first.

    Q: What’s your payment term?
    A: We accept T/T(30% down payment and balance before shipping) and L/C mostly, but if you prefer other payment terms please contact us for further information.

    Q: How long is your delivery time?
    A: Usually, it is 7-10 workdays if the goods are in stock, or it is 15-20 working days if the goods are not in stock, it is according to quantity.

    Q: Can we paint our label on your product?
    A: Of course. OEM and ODM are acceptable, please send us your logo or brand, we’ll paint for you.
